HiBoost Quad Band Booster Kit – Hi10-4S-Pro 4G/3G/2G

€900.00 including 23% VAT

SET-UP AND MONITORING VIA THE HIBOOST APP

HiBoost is powered by a free HiBoost App, Signal Supervisor. Now you can control your device directly from your phone or tablet at anytime from anywhere and benefit from much easier and more efficient installation.

  Go through all installation steps with a comprehensive guide and find the best position for the outdoor antenna with a professional signal meter tool

  Keep informed on booster performance status thanks to push notifications

  Receive assistance online from competent tech experts

POWERFUL NETWORK PROTECTION

All HiBoost signal repeaters feature smart AGC function that guarantees smart auto setup according to the level of outdoor signal reception and protection of your operator’s network.

HOW IT WORKS

1. The outdoor antenna picks up the signal from the nearest cell tower and sends it to the booster.

2. The booster amplifies or literally repeats the signal and transmits it to the indoor antenna.

3. The indoor antenna spreads the enhanced the signal throughout the desired area.

4. This is the moment! Your mobile phone receives a strong signal and you enjoy seamless calls and data!

TECH SPECS

Working Bands 800, 900, 1800, 2100 MHz
UL Frequency Range 832-862 / 880-915 / 1710-1785 / 1920-1980
DL Frequency Range 791-821 / 925-960 / 1805-1880 /2110-2170
Supported Standards EGSM, WCDMA, DCS and LTE800
Maximum Gain Uplink 60 dB, Downlink: 65 dB
Max. Output Power Uplink 20 dBm, Downlink: 10 dBm
MGC (Step Attenuation) ≥ 31 db/ 1 db step
Intelligent AGC ALC ≥22dB
ISO ≥22dB
Gain Flatness Typical≤5dB (p-p)
Noise Figure @ Max. System Gain Typical≤5dB
V.S.W.R Typical≤2
Group Delay ≤1μs
Frequency Stability ≤0.01ppm
Power Supply Input AC 90~264 V, 50/60 Hz, Output DC 12V/4A
Power Consumption ≤20W
Impedance 50 ohm
I/O port SMA-Female
Dimensions 6.7*10.4*2.1 inch/171*266*55mm
Booster Weight ≤5.5lbs/2.5KG
Booster Kit Weight 2.5KG
Operating Temperature -10ºC~+55ºC
Storage Temperature -10ºC~+80ºC
Relative Humidity 5% – 95%
Barometric Pressure 55 kPa -106 kPa
Environment Condition IP40

Categories: ,

Description

Product Description

Hi10-4S-Pro

All Networks (Ireland) | Four Band 500 – 1500 sq.m.

  • Networks : EGSM 900, DCS 1800, 3G 2100, 4GLTE 800
  • Coverage : up to 1500 square meters
  • Max.Gain : 65 dB
  • Suitable for a small home or office
  • Light and stylish
  • CE RED
  • Compliant with ComReg requirements

The Hi10-4S-Pro mobile signal repeater is an efficient solution for poor reception in a small home or office up to 1500 square meters. Put an end to dropped calls and slow data rates and stay connected!

stay always connected

Your struggle with poor reception is over! Hi10-4S-Pro mobile signal amplifier is a perfect signal solution for a small home or office.

Supporting 4 frequency bands at a time, the device delivers faster data speeds, endless streaming and clearer calls. It’s also compatible with all mobile operators in the UK and EU. Compliant with Ofcom VTS requirements.

* Mind that in order to receive maximum signal inside your home/office, you should pick up at least 2-3 bars outside it. The repeater coverage area also depends on design features of your building.
